| Model | FY 2125IJ-N | FY 2165IJ-N | FY 2185IJ-N | FY 2205IJ-N | FY 2225IJ-N(定制） |
| Medium width | 130CM | 170CM | 190CM | 210CM | 230CM |
| Print width | 120CM | 160CM | 180CM | 200CM | 220CM |
| Machine size | L200xW49 xH103CM | L240 xW49 xH105CM | L260 xW49 xH105CM | L280 xW49 xH105CM | L300 x W49 xH105CM |
| Duter package size | L210xW52 xH49CM | L243 x W52 xH49CM | L273 xW52 xH49CM | L293 x W52 x H49CM | L313 xW52 xH49CM |
| Printing speed | Double spray two-way high speed print≤90 m2/h | ||||
| Interface language | HP-GL instruction, PLT format file, compatible with domestic and foreign clothing CAD software print file | ||||
| Number /type of nozzles | Double spray /four spray- HP universal 6145A1 B ink cartridge | ||||
| Print head dleaning | Automatic cleaning before printing, support manual cleaning | ||||
| Resolution /wire number | 150-600dpi, line cleaning round smooth, line thickness can be selected pixel 1-8 | ||||
| Communication port | TCP network port, support single line 1-100m network cable, support direct connection computer or router, multiple computers control printing | ||||
| Media type | Suitable for roller type CAD mark carrier paper, kraft paper, 40-120g/m2 | ||||
| Drive motor | The motor uses a closed loop pattern, parsing positioning accurate, and the line is round. | ||||
| Equipment panel | Touch button, Chinese and English double board, simple and durable | ||||
| Supply voltage | AC220V 1 50-60Hz (AC110V can be customized), UPS power should not be less than 600W | ||||
| Environmental Science | Temperature 1-35 'C humidity rh15-85%(no condensate） | ||||
| Technical support | Provide telephone, network online and other means of technology on weekdays | ||||
| Loading /receiving system | The fron automatic delvery method, hiden sensor device saves equipment footprint.The heating device can cary50kg rollpape.Automaic paper storage system,exemption | ||||
| Machine structure | The whole machine main material adopts the mold aluminum alloy material of the reinforced hardness, high standardization accuracy, and aesthetics | ||||
| Control management software | Running platform Windows XP / NT 1 2000 / win10.The output printing center can control the equioment operation in real time.Support manual automatic printing, (Support the seling of equipment operation parameters. @lnk saving mode of nozzle printing is optional. Real time display ooutput printing status. Click and print any segment, and automatically paginate the super width. | ||||
